Intel® Apollo Lake E3900 series & N series Processor

Palm-size form factor: 128 (L) x 152 (W) x 37 mm(H)

Supports 2 x COM port, 1 x HDMI, 1 x Display Port, 2 x USB3.0, TPM and DCIN 12~24V

Built-in 1x M.2 expansion slot (i.e.: Wi-Fi module), 1 x Half size Mini PCIe expansion slot (i.e.: Zigbee, module or mSATA) and 1 x Full size Mini PCIeexpansion slot (i.e.: 3G/LTE module) with 5Antennas

Supports 1x 2.5" HDD or SSD storage

Wide operating temperature -20 ~ 60 °C support (With E3900 Series SoC)

IoT SW integration: WISE-PaaS IoT software platform, AWS Greengrass, Microsoft IoT Edge

Support OS: Windows 10, Linux OS

Support SUSI, WISE-DeviceOn and Edge AI Suite.

NVIDIA® Jetson TX2 Dual-Core NVIDIA Denver2 + Quad-core ARM Cortex-A57

NVIDAI® Pascal™ 256 CUDA cores GPU

8GB LPDDR4 and 32GB eMMC NAND Flash onboard

1Gigabit Ethernet ports and 2 PoE port (IEEE 802.3af)

TensorRT/cuDNN, VisionWorks/OpenCV AI framework support

4K H.264/H.265 encoder & decoder

-20 ~ 60 °C operating temperature/ 19V DC Power supply

Intel® Atom N3350 Dual Core SoC

Semi-Industry Fanless slim systen, Din Rail or Wall mount design

VGA display, COM port, 2 USB3.0, 1 LAN at Front

1 DIO port, 1 COM port at Side

Supports iManager, SUSI APIs, WISE-DeviceOn and Edge AI Suite

*No RED certification

Freescale ARM Cortex-A9 i.MX6 Dual Lite 1 GHz high performance processor

Onboard DDR3 1 GB, 4 GB eMMC Flash

Supports OpenGL ES 2.0 and OpenVG 1.1 hardware accelerators, full HD 1080p video codec

HDMI 1920x1080

Single Channel 18/24 bit LVDS

1 4-wire UART

1 USB 2.0, 1 USB OTG client

1 10/100/1000 Mbps Ethernet; 1 SD Slot

Dual mini-PCIe for WIFI/3G support

Multiple OS support in Linux/Android

Qualcomm Atheros Quard-Core ARM Cortex-A7 SoC

Built-in Dual Band Concurrent Wi-Fi MU-MIMO (2x2)

WAN x1 / LAN x1 Gigabit Ethernet

Integration of Modbus TCP and Modbus RTU networks

IPSec / L2TP VPN Traffic Encryption

Rich Network Scanrio by S/W Configuration

Modularization hardware design

OpenWRT BSP embeded

Web UI user interface

All-in-One RISC-based Intelligent and Industrial platform with Freescale i.MX6 Dual Cortex-A9 1.0 GHz processor

Compliant to 6LoWPAN and IEEE 802.15.4e standards

Supports up to 100/ 200 Wireless nodes

Power saving mode and fanless design

Integrated with WISE-PaaS/RMM for IoT Software Platform

No RED Certification

Intel Atom E3940 Quad Core SoC turbo burst up to 1.8 GHz

DIN-Rail system with essential I/O ports on front-side bezel

2 x Intel GbE and 4 x USB 3.0

Dual HDMI display up to 4K resolution

1 x full-size mPCIe with SIM holder and 1 x M.2 2230 for WIFI

1 x 2.5” SATA III SSD and 1 x full-size mSATA*

12V ~ 28V wide range power input

Advantech WISE-PaaS support

No RED Certification

Gen 8th Intel® Core™ i5/Celeron

Dual DDR4 2400MHz SO-DIMM memory up to 32G

1 x swappable 2.5" SATA HDD drive bay and 1 x mSATA slot, supports Intel software RAID 0/1

4 x USB 3.1 Gen 2, 2 x Intel GbE LAN, 4 x RS-232/422/485, 8 bit GPIO

4K2K HDMI and VGA dual independent displays

1 x full-size mPCIe with SIM holder and 1 x M.2 2230 E Key

Support Advantech SQF PCIex2 NVMe storage

12V - 24V @ -10%/+20% wide range power input

RED for WiFi/BT/LTE are available

Intel Celeron N3350 Dual Core SoC

1 x Full-size miniPCIe with SIM holder for communication module

1x M.2 E-key for WIFI module

-20 ~ 60 °C extended operating temperature

TPM 2.0 default built-in

Optional 12~24V power module (Dual Layer)

Advantech iDoor module compatible (Dual Layer)

Advantech WISE-DeviceOn support

FCC and RED for WiFi/BT are available with AMO-WIFI10 in single layer SKU

Intel 11th gen. Core i5/i3/Celeron

Pre-installed Edge X with data acquisition API

Empowered by Hailo-8 M.2 AI module up to 26 TOPS

8/16 GB Dual-Channel DDR4 Memory Built-in

64 GB SATA Slim SSD Built-in

4K HDMI and DP 1.4 Dual Display

Compatible with optional VEGA-330 AI Module supported by Intel Movidius Myriad X VPU

Intel VNNI support for AI and deep learning

Pre-installed WISE-DeviceOn for device management & remote control & quick AI deployment at scale
